GENERAL ITEMS |
|
|
|
SUPPLY TYPE |
ME/AF: CBU |
|
DESTINATION |
ME/AF |
|
FC COLOUR |
Black with silver deco |
|
TUNNING |
NUMBER OF PROGRAMS |
999 |
|
COLOUR SYSTEM |
PAL/NTSC, DVB-T/T2 |
|
SOUND SYSTEM |
BG / I / DK |
|
DTV SYSTEM |
DVB-T/T2 |
|
BASIC INFO |
CPU |
CA9 *2, 896MHz |
|
GPU |
GPU Mali-400*2 |
|
OS |
LINUX V3.10 |
|
MEMORY FLASH |
768M DDR/4GB EMMC |
|
INTERNET LINK |
BUILD IN WIFI,ETHERNET NETWORK |
|
PICTURE |
RESOLUTION |
1920x1080 |
|
ASPECT RATIO |
16:9 format, 4:3 format, Cinerama, 16:9 Zoom, 16:9 zoom up, 14:9 zoom |
|
DNR (Noise Reduction) |
YES, Off/Low/Middle/High/Auto |
|
Picture Mode |
Standard,Dynamic,Natural,Movie,Stadium,Personal |
|
AUDIO |
AUDIO OUTPUT POWER (RMS) |
10W x 2 |
|
SPEAKER TYPE |
Box |
|
FEATURES |
HOTEL MODE |
Yes |
|
PANASONIC LOGO |
YES |
|
CEC |
NO |
|
SOUND OUT(ARC） |
YES |
|
DIGITAL DOLBY |
Yes |
|
ANY OTHER (PLEASE SPECIFY) |
Netflix,Youtube, Browser, APP STORE,Hungama, YUPPTV, EROS NOW, Icflix |
|
CONNECTIVITY |
RF IN |
YES |
|
DTV IN |
Common with RF |
|
AV1 IN |
YES |
|
AV2 IN |
NO |
|
AV OUT |
NO |
|
DVD COMPATIBILITY (YPbPr/YCbCr) |
NO |
|
USB INPUT (3.0 SUPPORT) |
NO |
|
USB INPUT (2.0 SUPPORT) |
2 |
|
HDMI INPUT(2.0 SUPPORT) |
3 |
|
HEADPHONE OUT |
NO |
|
PC AUDIO IN |
NO |
|
PC(VGA IN) |
NO |
|
MHL |
NO |
|
AUDIO OUT |
YES |
|
SPDIF OUT |
YES |
|
RJ-45 |
YES |
|
ANY OTHER (PLEASE SPECIFY) |
NO |
|
MULTIMEDIA SUPPORT |
USB DEVICE SUPPORT |
USB 2.0 |
|
PICTURE FORMAT |
Jpeg/Png/BMP |
|
AUDIO FORMAT |
MP3, AAC |
|
VIDEO FORMAT |
H.264,H.265,MPEG1/2/4,WMV,VC1,VP8,VP9 |
|
PANEL SPECIFICATIONS |
PANEL MODEL NO. AND TYPE |
CSOT ST5461B03-5/VA |
|
SCREEN SIZE & DIAGONAL |
55” / 138.8CM |
|
ASPECT RATIO |
16:09 |
|
RESOLUTION |
1920(H) X 1080 (V) |
|
DISPLAY AREA(H x V) |
1209.6(H) * 680.4 (V) |
|
PIXEL PITCH |
0.63x0.63 |
|
DISPLAY COLOURS |
16.7 M(8bit) |
|
CONTRAST RATIO |
4000:1 |
|
MAX BRIGHTNESS |
280cd/m² |
|
VIEWING ANGLE (HORIZONTAL / VERTICAL) |
178°/178° |
|
WEIGHT AND DIMN. |
NET WEIGHT WITH PEDESTAL |
13.2KG |
|
NET WEIGHT W/O PEDESTAL |
13KG |
|
NET DIMENSIONS WITH PEDESTAL |
1242mm*775.65mm*269.5mm |
|
NET DIMENSIONS W/O PEDESTAL |
1242mm*719.3mm*84.3mm |
|
GROSS DIMENSIONS (PACKING BOX) |
1400*160*856mm |
|
GROSS WEIGHT (WITH PACKING BOX) |
17KG |
|
RATING |
OPERATING VOLTAGE |
110V-240V~ at 50/60Hz |
|
POWER CONSUMPTION |
130 W |
|
STD BY POWER CONSUMPTION |
≤0.5W |
|
ACCESSORIES |
REMOTE |
N2QAYB001008 |
|
BATTERY |
2 "AA" Batteries |
|
POWER CORD TYPE |
Detachable |
|
POWER CORD |
ME/AF: VED 2PIN+BS 3PIN |
|
POWER PLUG |
2 PIN |
|
ANY OTHER (PLEASE SPECIFY) |
-- |
|
REGULATION |
BIS |
No |
|
CB |
YES |
|
ERP |
YES |
|
EMC |
YES |
|
BEE |
NO |
|
