Power supply                  100-240 V AC, 50/60 Hz
Power consumption        461 W (0.3 W with Standby Mode set to Eco*1,
8 W with Standby Mode set to Normal)
12 W with Standby Mode set to Normal)
LCD Panel Panel size     16.3 mm (0.64 in) diagonal (16:10 aspect ratio)
                   Display method   Transparent LCD panel (x3, R/G/B)
                   Drive method       Active matrix
                   Pixels            1,024,000 (1,280 x 800) x 3, total of 3,072,000 pixels
Lens           PT-EW650   Powered zoom (throw ratio 1.22-2.26:1), powered focus, F 1.6-2.2, f 17.1-31.7 mm
Lamp                               320 W UHM lamp x 1
Lamp replacement cycle 4,000 hours*2 (lamp power: Normal), 5,000 hours*2 (lamp power: Eco)
Screen size (diagonal)     1.03-10.57 m (40-400 in), 16:10 aspect ratio
Brightness*3                   5,800 lm (lamp power: Auto/Normal, Dynamic Mode, standard lens)
Center-to-corner uniformity*3           90%
Contrast*3                      10,000:1 (full on/full off, lamp power: Auto, Iris: ON)
Resolution                       1,280 x 800 pixels*4
Scanning    HDMI          Dot clock: 25-162 MHz
Frequency  DIGITAL LINK (VGA: 640 x 480 pixels to WUXGA: 1,920 x 1,200 pixels, VESA CVT-RB compliant with HDCP)
(DIGITAL LINK not included on PT-EW550/EW550L.)
                   RGB             fH: 15-91 kHz, fV: 24-120 Hz, dot clock: up to 162 MHz
                   YPBPR (YCBCR)          fH: 15.73 kHz, fV: 59.94 Hz [480i (525i)]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
fH: 31.47 kHz, fV: 59.94 Hz [480p (525p)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]
                   Video/YC    fH: 15.73 kHz, fV: 59.94 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis                     Vertical       ±60% (powered)
Shift           Horizontal    ±30% (powered)
Keystone correction range*5 Vertical ±30°, horizontal ±25°
Installation                      Ceiling/floor, front/rear
Built-in speaker               3.7 cm round shape × 1, output power: 10.0 W (monaural)
Terminals   HDMI IN     HDMI 19-pin x 2 (Deep Color, compatible with HDCP),
audio signal: Linear PCM (Sampling frequency: 48 kHz/44.1 kHz/32 kHz)
                   RGB 1 IN    BNC x 5 (RGB or YPBPR/YCBCR x 1), shared with VIDEO IN (S-video/composite video)
                   RGB 2 IN    D-Sub HD 15-pin (female) x 1
                   VIDEO IN   Pin jack x 1 (composite video)
                   MONITOR OUT D-sub HD 15-pin (female) x 1 (RGB x 1) (compatible with RGB or YPBPR/YCBCR)
                   AUDIO IN  Pin jack x 2 (L/R x 1), M3 x 2 (L-R x 2)
                   AUDIO OUT      M3 x 1 (L-R x 1) for output (variable)
                   SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                   REMOTE 1 IN    M3 x 1 for wired remote control
                   REMOTE 2 IN    D-sub 9-pin (female) x 1 for external control (parallel)
                   LAN             RJ-45 x 1 for network connection, 10Base-T, 100Base-TX, compatible with PJLink™
                   DIGITAL LINK RJ-45 x 1 for network and DIGITAL LINK connection,
100Base-TX, compatible with PJLink™, HDCP, Deep Color
                   USB-A         2 (Network/Wireless x 1, 5 V/0.9 A x 1)
Operation noise*3           35 dB (lamp power: Normal), 29 dB (lamp power: ECO)
Filter                               x1, replacement cycle: up to 15,000 hours*6
Mechanical shutter          Yes
Cabinet materials            Molded plastic (PC + ABS)
Dimensions (W x H x D)       498 x 145*7 x 398.3 mm (19-19/32 x 5-23/32*7 x 15-11/16 in) (with supplied lens)
Weight*8                        Approx. 9.0 kg (19.8 lbs) (with supplied lens)
Operating environment   Operating temperature: 0-45 °C (32-113 °F)*9,
operating humidity: 20-80 % (no condensation)

Note:                               The PT-EZ590L/EW650L/EW550L delivers the same performance as the PT-EZ590/EW650/EW550, but comes without a lens.
*1 When Standby Mode is set to Eco, network functions such as power on over LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*2 This is the maximum value when the lamp is turned on for 2 hours and off for 0.25 hours. If the lamp is turned on more times or kept on for a long time, lamp replacement cycle will shorten. Usage environment affects the duration of the lamp.
*3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4 Input signals that exceed supported resolution will be converted.
*5 With the supplied lens. Value differs when the correction for both directions is operated.
*6 Usage environment affects the duration of the filter.
*7 With legs at shortest position.
*8 Average value. May differ depending on models.
*9 Operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when used at altitudes from 1,400 m to 2,700 m (4,593 ft to 8,858 ft) above sea level. Also, if ambient temperature exceeds 40 °C (104 °F) (35 °C [95 °F] at high altitude), lamp power may automatically switch to Eco to in order to protect the projector.
