Power supply                                           100–240 V AC, 50/60 Hz
Power consumption                                  350 W (0.45 W when STANDBY MODE set to ECO,*1
11.0 W when STANDBY MODE set to NETWORK.)
DLP™ chip                 Panel size                 16.5 mm (0.65 inches) diagonal
(16:10 aspect ratio)
                               Display method         DLP™ chip x 1 DLP™ system
                               Pixels                      1,024,000 (1,280 x 800) pixels
Lens                                                       Fixed (0.19:1 throw ratio),
manual focus F = 2.5, f = 4.83 mm
Lamp                                                      275 W UHM lamp (The lamp replacement cycle is 3,000 hours)
Screen size (diagonal)                                1.52-2.79 m (60-110 inches)
(16:10 aspect ratio)
Color reproducibility                                  Full color (16,777,216 colors)
Brightness                                               2,500 lm (lamp power: Normal)
Center-to-corner uniformity ratio *2               80%
Contrast                                                  2,000:1 (full on/off, lamp power: Normal)
Resolution                                               1,280 x 800 pixels
(Input signals that exceed this resolution
will be converted to 1,280 x 800 pixels.)
Scanning frequency     HDMI                       (Horizontal) 15-93 kHz; (Vertical) 50-120 Hz; (Dot clock) 150 MHz or lower
                               RGB (analog)            (Horizontal) 15-93 kHz; (Vertical) 50-120 Hz; (Dot clock) 150 MHz or lower
(Signals exceeding the dot clock rate of 150 MHz are downsampled.)
                               YPBPR (YCBCR)        fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]            fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
                               S-Video/Video           fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Installation                                              Ceiling/floor, front/rear (Menu setting)
Built-in speaker                                        3.7 cm round shape x 1, output power 10 W (monaural)
Keystone correction range                          Vertical: ±5°
Terminals                  HDMI IN                   HDMI 19-pin x 1(compatible with HDCP)
Audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
                               COMPUTER IN 1        D-sub HD 15-pin (female) x 1 [RGB/YPB(CB)/PR(CR)x 1]
                               COMPUTER IN 2 / MONITOR OUT         D-sub HD 15-pin (female) x 1 (RGB x 1) (input/output selectable using on-screen Menu)
(When Monitor Out is selected, the COMPUTER IN 1 signal is output.)
                               VIDEO IN                  RCA pin x 1
                               S-VIDEO IN               Mini DIN 4-pin x 1
                               COMPUTER 1 AUDIO IN         M3 x 1 (L-R x 1)
                               COMPUTER 2 AUDIO IN         M3 x 1 (L-R x 1)
                               AUDIO IN                 RCA pin x 2 (L/R x 1) for VIDEO/S-VIDEO input
                               AUDIO OUT              M3 x 1 (L-R x 1) for output (variable)
                               SERIAL IN                D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                               LAN                        RJ-45 x 1 (for network connection, 100BASE-TX/10BASE-T,
compliant with PJLink™ (class 1))
                               3D SYNC OUT           Mini DIN 3-pin x 1 (for 3D transmitter connection)
Power cord length                                     3.0 m (9'10")
Cabinet material                                        Molded plastic (PC)
Dimensions (W x H x D)                              321 x 178 x 386 mm (12-5/8" x 7" x 15-3/16")
(with legs at shortest position)
Weight                                                    Approximately 6.2 kg (13.7 lbs)
Noise level                                               36 dB (Lamp power: Normal); 28 dB (Lamp power: Eco)
Operating Temperature                              0°C-40°C [32°F-104°F] (Less than 1,000 m [3,281 ft] above sea level)
0°C-30°C [32°F-86°F] (between 1,000 and 2,700 m [3,281 ft and 8,858 ft] above sea level)
Operating humidity                                   20%-80% (no condensation)
