Power supply                                 100-240 V AC, 50/60 Hz
Power consumption                       300 W
(0.5 W when STANDBY MODE set to ECO,^*1 6 W when STANDBY MODE set to Normal.)
LCD panel          Panel size            15.0 mm (0.59 in) diagonal (16:10 aspect ratio)
                            Display method  Transparent LCD panel (x 3, R/G/B)
                            Pixels                  1,024,000 (1,280 x 800) x 3, total of 3,072,000 pixels
Lens                                               1.2x manual zoom (throw ratio: 1.48-1.78:1),
manual focus, F=1.6-1.76, f=19.16-23.02 mm
Lamp                                              230 W x 1,
lamp replacement cycle (lamp control: Normal/Eco1/Eco2): 5,000 hours/6,000 hours/8,000 hours^*2
Screen size (diagonal)                    0.76-7.62 m (30-300 in), 16:10 aspect ratio
Brightness^*3
(Lamp control: Normal)                 3,300 lm
Center-to-corner uniformity^*3        80 %
Contrast^*3                                       10,000:1 (full on/off)
(RGB signal input, Lamp control: Normal, Color mode: Dynamic, Iris: On)
Resolution                                      1,280 x 800 pixels^*4
Scanning frequency                       HDMI IN            fH: 15-91 kHz, fV: 50-85 Hz, dot clock: 25 MHz-162 MHz
                            RGB                   fH: 15-91 kHz, fV: 50-85 Hz, dot clock: 162 MHz or lower
                            YPBPR(YCBCR)    fH: 15.75 kHz, fV: 59.94 Hz [480i (525i)]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
fH: 31.47 kHz, fV: 59.94 Hz [480p (525p)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]
                            Video/S-Video   fH: 15.73 kHz, fV: 59.94 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/SECAM/PAL-N]
Optical axis shift                            13:1 (fixed)
Keystone correction range             Vertical    ±30°
                            Horizontal          ±15°
Installation                                     Ceiling/floor, front/rear
Terminals            HDMI IN           HDMI 19-pin x 1 (compatible with HDCP, Deep Color)
480i^*5, 480p, 576i^*5, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i,
1080/25p, 1080/24p, 1080/24sF, 1080/30p,
1080/60p, 1080/50p, VGA (640 x 480)-WUXGA (1,920 x 1,200),^*6
audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
                            COMPUTER 1 IN D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR /S-VIDEO x 1)
(The D-Sub/S-VIDEO conversion cable ET-ADSV is required for inputting S-VIDEO signals.)
                            COMPUTER 2 IN/
MONITOR OUT                           D-sub HD 15-pin (female) x 1 (RGB x 1), (input/output selectable using on-screen menu)
                            VIDEO IN         Pin jack x 1 (Composite VIDEO)
                            AUDIO 1 IN     M3 x 1 (L-R x 1)
                            AUDIO 2 IN     Pin jack x 2 (L, R x 1)
                            AUDIO OUT     M3 x 1 (L-R x 1) for output (variable)
                            SERIAL IN       D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                            LAN                   RJ-45 x 1
(for network connection, 10BASE-T/100BASE-TX, compliant with PJLink^™)
                            USB A               USB type-A (for the Memory Viewer) x 1
                            USB B                USB type-B (for the USB Display) x 1
Built-in speaker                              -
Noise level^*3                                   37 dB (lamp control: Normal), 33 dB (lamp control: Eco1), 28 dB (lamp control: Eco2)
Cabinet materials                           Molded plastic (PC)
Dimensions (W x H x D)               335 mm x 96 mm^*7 x 252 mm (13-3/16 x 3-25/32^*7 x 9-29/32 in)
Weight^*8                                         Approx. 2.8 kg (6.2 lbs)
Operating temperature                   5°C-40°C (41°F-104°F)
(less than 1,400 m [4,500 ft] above sea level),
5°C-35°C (41°F-95°F)
(between 1,400 m and 2,700 m [4,500 ft and 8,800 ft] above sea level)
Operating humidity                        20-80 % (no condensation)

NOTE                                            *1 When the Standby mode is set to Eco, network functions such as power on over the LAN network will not operate.
Also, only certain commands can be received for external control using the serial terminal.
*2 The value for the recommended lamp replacement cycle is the maximum value, at which luminance will become 50 %.
The usage environment affects the duration of the lamp.
*3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4 Input signals that exceed this resolution will be converted to 1,280 x 800 pixels.
*5 Only compatible with dot clock frequency of 27 MHz (pixel repetition signal).
*6 Compliant with VESA CVT-RB.
*7 With legs at shortest position.
*8 The above values are averages. Actual values may be different according to the product.
