Panel Type 0.59" LCD x 3
Lamp 270W x 1
Brightness 5000 lumens
Lens F1.60-1.90, f15.31-24.64mm
Contrast (Full on / Full off) 10000:1
Resolution (Native / maximum) WXGA
H-Sync/V-Sync Range RGB: 15-91 kHz / 24-100 Hz
Video Compatibility PAL, PAL-M, PAL-N, PAL60, "PAL, PAL-M, PAL-N, PAL60,
SECAM, NTSC, NTSC4.43
Screen Size 30" - 300"
Lens Shift Vertical ±48°
Keystone Correction Range Vertical ±35°; horizontal ±35°
Weight Approx 4.9kg
Dimensions (W x H x D) 389 x 125 x 332 mm
Power Consumption 369W (Standby mode : 0.4W(eco), 14W(normal))
Terminals Serial (D-sub 9-pin x 1); LAN/DIGITAL LINK (RJ-45 x 1, 10Base-T/10/100Base-TX)
Audio 1(M3 jack (L/R x 1)
Audio 2(M3 jack (L/R) x1/mic in)
Audio 3(Pin jack (L/R) x 1)
Audio out (M3 jack (L/R) x 1(mon out))
Composite video (RCA x 1)
PC1 (D-sub HD 15-pin x 1); PC2 in/out (D-sub HD 15-pin x 1)
HDMI (19-pin x 2)
USB A: Type A (Memory Viewer x 1)
USB B: Type B (USB display x 1)
Replacement Lamp ET-LAV400
Optional Accessories ET-RFV400 (Replacement filter unit)
