General  Power supply                        100 - 240 V AC, 3.9 - 1.4 A, 50/60 Hz
              Power consumption              330 W (0.3 W at 100 - 120 V AC, 0.4 W at 220 - 240 V AC when standby mode set to eco*1, 9 W when standby mode set to normal, 20 W when standby mode set to normal and audio monitor out.)
              LCD panel  Panel size           18.9 mm (0.74 inches) diagonal (16:10 aspect ratio)
                                  Display method Transparent LCD panel (× 3, R/G/B)
                                  Pixels                 1,024,000 (1,280 × 800) × 3, total of 3,072,000 pixels
                                  Pixel configuration       Stripe
              Lens                                      Manual 2× zoom (throw ratio: 1.34 - 2.68:1), manual focus F 1.7 - 2.6, f 21.6 - 43.0 mm
              Lamp                                     250 W UHM lamp (The lamp replacement cycle is 6,000 hours.*2)
              Screen size (diagonal)           0.84 - 7.62 m (33 - 300 inches), 16:10 aspect ratio
              Brightness*3                         3,500 lm (lamp mode: normal)
              Center-to-corner uniformity*3         80%
              Contrast*3                            600:1 (full on/full off)
              Resolution                             1,280 × 800 pixels (Input signals that exceed this resolution will be converted to 1,280 × 800 pixels.)
              Scanning frequency              HDMI/DVI-I (digital)           fH: 27.0 kHz - 68.7 kHz; fV: 24.0 Hz - 85.0 Hz; dot clock: 25.2 MHz - 148.5 MHz
                                  DVI-I (analog)/RGB    fH: 15 .6 kHz - 91.1 kHz; fV: 24.0 Hz - 85.1 Hz; dot clock: 162 MHz or lower
                                  YPBPR (YCBCR)       fH: 15.75 kHz; fV: 60 Hz [480i (525i)]
fH: 31.50 kHz; fV: 60 Hz [480p (525p)]
fH: 45.00 kHz; fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz; fV: 60 Hz [1080 (1125)/60i]
fH: 27.00 kHz; fV: 24 Hz [1080 (1125)/24p]
fH: 67.50 kHz; fV: 60 Hz [1080 (1125)/60p]
                                  Video/S-Video  fH: 15.75 kHz; fV: 60 Hz (NTSC/NTSC4.43/PAL-M/PAL60), fH: 15.63 kHz; fV: 50 Hz (PAL/PAL-N/SECAM)
              Optical axis shift                   Vertical           ±51% from center of screen (manual)
                                  Horizontal          ±24% from center of screen (manual)
              Keystone correction range    Vertical: ±30°
              Installation                            Ceiling/desk, front/rear
              Built-in speaker                     Output power: 5.0 W (monaural)
              Terminals    HDMI IN          HDMI 19-pin × 1 (Deep Color, compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/60p, 1080/50p,
VGA (640 × 480) - WSXGA+ (1,680 × 1,050), compatible with non-interlaced signals only;
dot clock: 25.2 - 146.25 MHz;
Audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
                                  DVI-I IN           DVI-I 29-pin × 1
Digital: (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/60p, 1080/50p,
VGA (640 × 480) - WSXGA+ (1,680 × 1,050), compatible with non-interlaced signals only;
dot clock: 25.2 - 146.25 MHz;
Analog: (RGB/YPBPR (YCBCR))
                                  COMPUTER (RGB) IN          D-sub HD 15-pin (female) × 1 (RGB/YPBPR × 1)
                                  VIDEO IN        RCA pin × 1 (composite video)
                                  S-VIDEO IN     Mini DIN 4-pin × 1 (S-Video)
                                  AUDIO IN 1     M3 × 1 (L, R × 1), 0.5 Vrms
                                  AUDIO IN 2     M3 × 1 (L, R × 1), 0.5 Vrms
                                  AUDIO IN 3     RCA pin × 2 (L, R × 1), 0.5 Vrms
                                  AUDIO OUT    M3 × 1 (L, R × 1) (monitor out: 0 - 2.0 Vrms, variable)
                                  SERIAL IN       D-sub 9-pin (female) × 1 for external control (RS-232C compliant)
                                  LAN                  RJ-45 × 1 (for network connection, 10Base-T/100Base-TX, compliant with PJLink™)
                                  WIRELESS MODULE           Connector for optional wireless module ET-WM200 × 1
              Cabinet materials                  Molded plastic (PC+ABS)
              Dimensions (W × H × D)      430 × 125.5*4 × 323 mm (16 - 15/16˝ × 4 - 15/16˝ *4 × 12-23/32˝ ) (Protruding parts not included)
              Weight                                  Approximately 6.0 kg (13.2 lbs.)
              Operating environment         Operating temperature: 0°C - 40°C (32°F - 104°F)*5; operating humidity: 20% - 80% (no condensation)

NOTE                                                  *1 When the standby mode is set to eco, network functions such as power on over the LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*2 This value is calculated by continuously turning the lamp on for 2 hours and off for 0.25 hours. The lamp replacement cycle will decrease if the lamp is turned on/off more frequently, or if it is left on for longer intervals.
*3 Measurement, measuring conditions and method of notation all comply with ISO 21118 international standards.
*4 With legs at shortest position.
*5 The operating temperature range is 0°C to 35°C (32°F to 95°F) when used in High- Altitude mode (1,400 m to 2,700 m (4,593 ft to 8,858 ft)).
