مشخصات:
General Power supply 100 – 240 V AC, 50/60 Hz
Power consumption 490 W (0.4 W with STANDBY MODE set to ECO,*1 11 W with STANDBY MODE set to NETWORK.)
LCD panel Panel size 19.0 mm (0.75 inches) diagonal (16:10 aspect ratio)
Display method Transparent LCD panel (x 3, R/G/B)
Drive method Active matrix
Pixels 1,024,000 (1,280 x 800) x 3, total of 3,072,000 pixels
Lens PT-EW530 / EX500 Powered zoom (throw ratio 1.7–2.8:1), powered focus F 1.7–2.3, f 26.9–45.4 mm
PT-EW530L / EX500L Optional powered zoom/focus lenses and fixed-focus lens
Lamp 330 W UHM lamp x 1, lamp replacement cycle: 4,000 hours*2
Screen size (diagonal) 1.02–10.16 m (40–400 inches)
(16:10 aspect ratio)
Color reproducibility Full color (16,777,216 colors)
Brightness*3 4,500 lm (lamp power: Auto/Normal)
Center-to-corner uniformity*3 90%
Contrast*3 2,000:1 (full on/off, lamp power: Auto/Normal)
Resolution 1,280 x 800 pixels*4
Scanning frequency HDMI/DVI-D (Horizontal) 26–80 kHz; (Vertical) 23–85 Hz; (Dot clock) 162 MHz or lower
RGB (analog) (Horizontal) 15–120 kHz; (Vertical) 48–100 Hz; (Dot clock) 230 MHz or lower
(Signals exceeding the dot clock rate of 140 MHz are downsampled.)
YPBPR (YCBCR) fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1035/60i]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 28.13 kHz, fV: 50 Hz [1080/25sF]
fH: 27.00 kHz, fV: 48 Hz [1080/24sF]
fH: 33.75 kHz, fV: 60 Hz [1080/30sF]
fH: 56.25 kHz, fV: 50 Hz [1080/50p]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080/25p]
fH: 27.00 kHz, fV: 24 Hz [1080/24p]
fH: 33.75 kHz, fV: 30 Hz [1080/30p]
fH: 67.50 kHz, fV: 60 Hz [1080/60p]
Video/S-Video fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis shift*5 Vertical ±60% from center of screen (powered)
Horizontal ±10% from center of screen (powered)
Keystone correction range Vertical: ±40°*6
Installation Ceiling/floor, front/rear
Built-in speaker 3.7 cm round shape x 1, output power 10.0 W (monaural)
Terminals INPUT 1 - DVI-D IN DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
INPUT 1 - HDMI IN HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
INPUT 1 - RGB IN D-sub HD 15-pin (female) x 1 (RGB x 1)
INPUT 2 - RGB 5BNC IN/ VIDEO IN BNC x 5 (RGB/YPBPR/YCBCR x 1), shared with VIDEO IN (BNC x 1) (composite video)
INPUT 3 - COMPONENT/ VIDEO IN RCA x 3 (YPBPR/YCBCR/composite video x 1)
INPUT 3 - S-VIDEO IN Mini DIN 4-pin x 1
MONITOR OUT D-sub HD 15-pin (female) x 1 (RGB x 1)
AUDIO IN 1 M3 x 1 (L-R x 1)
AUDIO IN 2 M3 x 1 (L-R x 1)
AUDIO IN 3 RCA pin x 2 (L/R x 1) for VIDEO/S-VIDEO input
AUDIO OUT M3 x 1 (L-R x 1) for output (variable)
SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
REMOTE IN M3 Jack x 1 (for wired remote control)
LAN RJ-45 x 1 (for network connection, 100BASE-TX/10BASE-T, compliant with PJLink™ (class 1))
Cabinet materials Molded plastic (PC + ABS)
Dimensions (W x H x D) PT-EW530 / EX500 489.5 x 164*8 x 434 mm (19.3" x 6.5"*8 x 17.1") (with supplied lens)
PT-EW530L / EX500L 489.5 x 164*8 x 370 mm (19.3" x 6.5"*8 x 14.6") (without lens)
Weightl*7 PT-EW530 / EX500 Approximately 10.2 kg (22.5 lbs) (with supplied lens)
PT-EW530L / EX500L Approximately 9.5 kg (20.9 lbs) (with supplied lens)
Noise level*7 37 dB (Lamp power: Normal); 31 dB (Lamp power: Eco1 or Eco2)
Operating temperature 0°C–40°C (32°F–104°F)*9
Operating humidity 20% - 80% (no condensation)
NOTE * Product numbers vary depending on the market. The general guideline is as follows:
The product numbers in the Americas and Taiwan are PT-EW530U/PT-EW530UL and PT-EX500U/PT-EX500UL.
The product numbers in Europe, CIS, Asia (except Taiwan), Oceania, Middle East, and Africa are PT-EW530E/PT-EW530EL and PT-EX500E/PT-EX500EL.
*The PT-EW530L/EX500L delivers the same performance as the PT-EW530/EX500, but comes without a lens.
*1 When the STANDBY MODE is set to ECO, network functions such as power on over the LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*2 This is the maximum value when the lamp power is set to Eco1 or Eco2 mode where the lamp is turned on for 2 hours and off for 0.25 hours. If the lamp is turned on more times or kept on for a long time, the lamp replacement cycle will shorten. In Normal mode, the lamp replacement cycle is 3,000 hours. The usage environment affects the duration of the lamp
*3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4 Input signals that exceed the native resolution will be converted to the native resolution.
*5 The axis shift function cannot be used with the ET-ELW21.
*6 With the supplied lens. Value differs when the correction for both directions is operated.
*7 Average value. May differ depending on models.
*8 With legs at shortest position.
*9 The operating temperature range is 0 °C to 30 °C (32 °F to 86 °F) when the fan control is set to ON 1 for altitudes from 1,000 m to 2,000 m (3,281 ft to 6,562 ft) above sea level, 0 °C to 30 °C (32 °F to 86 °F) when the fan control is set to ON 2 for altitudes from 2,000 m to 2,700 m (6,562 ft to 8,858 ft) above sea level
