General  Power supply                              100 – 240 V AC, 50/60 Hz
              Power consumption                    490 W (0.4 W with STANDBY MODE set to ECO,*1
11 W with STANDBY MODE set to NETWORK.)
              LCD panel    Panel size               19.2 mm (0.76 inches)
diagonal (16:10 aspect ratio)
                                    Display method     Transparent LCD panel (x 3, R/G/B)
                                    Drive method        Active matrix
                                    Pixels                     2,304,000 (1,920 x 1,200) x 3, total of 6,912,000 pixels
              Lens              PT-EZ570 / EW630 / EX600 Powered zoom (throw ratio 1.7–2.8:1), powered focus F 1.7–2.3, f 26.9–45.4 mm
                                    PT-EZ570L / EW630L / EX600L      Optional powered zoom/focus lenses and fixed-focus lens
              Lamp                                           330 W UHM lamp x 1, lamp replacement cycle: 4,000 hours*2
              Screen size (diagonal)                 1.02–10.16 m (40–400 inches)
(16:10 aspect ratio)
              Color reproducibility                   Full color (1,073,741,824 colors)
              Brightness*3                               5,000 lm (lamp power: Auto/Normal)
              Center-to-corner uniformity*3    90%
              Contrast*3                                  5,000:1 (full on/off, lamp power: Auto/Normal, iris: On)
              Resolution                                   1,920 x 1,200 pixels*4
              Scanning frequency                    HDMI/DVI-D      (Horizontal) 26–80 kHz; (Vertical) 23–85 Hz; (Dot clock) 162 MHz or lower
                                    RGB (analog)        (Horizontal) 15–120 kHz;
(Vertical) 48–100 Hz;
(Dot clock) 230 MHz or lower
(Signals exceeding the dot clock rate of 163 MHz are downsampled.)
                                    YPBPR (YCBCR)     fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1035/60i]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 28.13 kHz, fV: 50 Hz [1080/25sF]
fH: 27.00 kHz, fV: 48 Hz [1080/24sF]
fH: 33.75 kHz, fV: 60 Hz [1080/30sF]
fH: 56.25 kHz, fV: 50 Hz [1080/50p]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080/25p]
fH: 27.00 kHz, fV: 24 Hz [1080/24p]
fH: 33.75 kHz, fV: 30 Hz [1080/30p]
fH: 67.50 kHz, fV: 60 Hz [1080/60p]
                                    Video/S-Video      fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
              Optical axis shift*5                     Vertical     ±60% from center of screen (powered)
                                    Horizontal             ±10% from center of screen (powered)
              Keystone correction range          Horizontal: ±30°*6, vertical: ±30°*6
              Installation                                  Ceiling/floor, front/rear
              Built-in speaker                           3.7 cm round shape x 1, output power 10.0 W (monaural)
              Terminals      INPUT 1 - DVI-D IN            DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
                                    INPUT 1 - HDMI IN HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
                                    INPUT 1 - RGB IN   D-sub HD 15-pin (female) x 1 (RGB x 1)
                                    INPUT 2 - RGB 5BNC IN/ VIDEO IN       BNC x 5 (RGB/YPBPR/YCBCR x 1), shared with VIDEO IN (BNC x 1) (composite video)
                                    INPUT 3 - COMPONENT/ VIDEO IN        RCA x 3 (YPBPR/YCBCR/composite video x 1)
                                    INPUT 3 - S-VIDEO IN       Mini DIN 4-pin x 1
                                    MONITOR OUT  D-sub HD 15-pin (female) x 1 (RGB x 1)
                                    AUDIO IN 1        M3 x 1 (L-R x 1)
                                    AUDIO IN 2        M3 x 1 (L-R x 1)
                                    AUDIO IN 3        RCA pin x 2 (L/R x 1) for VIDEO/S-VIDEO input
                                    AUDIO OUT        M3 x 1 (L-R x 1) for output (variable)
                                    SERIAL IN          D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                                    REMOTE IN        M3 Jack x 1 (for wired remote control)
                                    LAN                      RJ-45 x 1 (for network connection, 100BASE-TX/10BASE-T, compliant with PJLink™ (class 1))
              Cabinet materials                        Molded plastic (PC + ABS)
              Dimensions (W x H x D)            PT-EZ570 / EW630 / EX600       489.5 x 164*8 x 434 mm (19.3" x 6.5"*8 x 17.1") (with supplied lens)
                                    PT-EZ570L / EW630L / EX600L      489.5 x 164*8 x 370 mm (19.3" x 6.5"*8 x 14.6") (without lens)
              Weightl*7     PT-EZ570 / EW630 / EX600 Approximately 10.3 kg (22.7 lbs) (with supplied lens)
                                    PT-EZ570L / EW630L / EX600L      Approximately 9.6 kg (21.2 lbs) (with supplied lens)
              Noise level*7                              37 dB (Lamp power: Normal); 31 dB (Lamp power: Eco1 or Eco2)
              Operating temperature                0°C–40°C (32°F–104°F)*9
              Operating humidity                     20% - 80% (no condensation)
              Supplied accessories                   Power cord x 1 ( x 2 for PT-EZ570E/EZ570EL, PT-EW630/EW630EL, PT-EX600E/EX600EL), power cord holder/power cord cover x 1, wireless/wired remote control unit x 1, batteries (AAA/R03/LR03 type x 2), computer cable (1.8 m, for VGA) x 1, Software CD-ROM (Logo Transfer Software, Multi Projector Monitoring & Control Software) x1,
NOTE                                                        * Product numbers vary depending on the market. The general guideline is as follows:
The product numbers in the Americas and Taiwan are PT-EZ570U/PT-EZ570UL, PT-EW630U/PT-EW630UL and PT-EZ570U/PT-EZ570UL.
The product numbers in Europe, CIS, Asia (except Taiwan), Oceania, Middle East, and Africa are PT-EZ570E/PT-EZ570EL, PT-EW630E/PT-EW630EL and PT-EZ570E/PT-EZ570EL.
*The PT-EZ570L/EW630L/EX600L delivers the same performance as the PT-EZ570/EW630/EX600, but comes without a lens.

*1 When the STANDBY MODE is set to ECO, network functions such as power on over the LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*2 This is the maximum value when the lamp power is set to Eco1 or Eco2 mode where the lamp is turned on for 2 hours and off for 0.25 hours. If the lamp is turned on more times or kept on for a long time, the lamp replacement cycle will shorten. In Normal mode, the lamp replacement cycle is 3,000 hours. The usage environment affects the duration of the lamp
*3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4 Input signals that exceed the native resolution will be converted to the native resolution.
*5 The axis shift function cannot be used with the ET-ELW21 .
*6 With the supplied lens. Value differs when the correction for both directions is operated.
*7 Average value. May differ depending on models.
*8 With legs at shortest position.
*9 The operating temperature range is 0 °C to 30 °C (32 °F to 86 °F) when the fan control is set to ON 1 for altitudes from 1,000 m to 2,000 m (3,281 ft to 6,562 ft) above sea level, 0 °C to 30 °C (32 °F to 86 °F) when the fan control is set to ON 2 for altitudes from 2,000 m to 2,700 m (6,562 ft to 8,858 ft) above sea level.
