Power supply                        100-240 V AC, 50/60 Hz
Power consumption              484 W (0.3 W with Standby Mode set to Eco*1, 12 W with Standby Mode set to Normal)
LCD Panel      Panel size      16.3 mm (0.64 in) diagonal (16:10 aspect ratio)
                        Display method          Transparent LCD panel (x3, R/G/B)
                        Drive method Active matrix
                        Pixels            1,024,000 (1,280 x 800) x 3, total of 3,072,000 pixels
Lens                                      Powered zoom (throw ratio 1.22-2.26:1), powered focus, F 1.6-2.2, f 17.1-31.7 mm
Lamp                                    320 W UHM lamp x 1
Lamp replacement cycle       4,000 hours*2 (lamp power: Normal), 5,000 hours*2 (lamp power: Eco)
Screen size (diagonal)          1.03-10.57 m (40-400 in), 16:10 aspect ratio
Brightness*3                        5,800 lm (lamp power: Auto/Normal, Dynamic Mode, standard lens)
Center-to-corner uniformity*3           -
Contrast*3                            2,000:1 (full on/full off, lamp power: Auto)
Resolution                            1,920 x 1,200 pixels*4
Scanning         HDMI          Dot clock: 25-162 MHz
Frequency       DIGITAL LINK        (VGA: 640 x 480 pixels to WUXGA: 1,920 x 1,200 pixels, VESA CVT-RB compliant with HDCP)
(DIGITAL LINK not included on PT-EW550/EW550L.)
                        RGB             fH: 15-91 kHz, fV: 24-120 Hz, dot clock: up to 162 MHz
                        YPBPR (YCBCR)     fH: 15.73 kHz, fV: 59.94 Hz [480i (525i)]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
fH: 31.47 kHz, fV: 59.94 Hz [480p (525p)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]
                        Video/YC     fH: 15.73 kHz, fV: 59.94 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis     Vertical         ±60% (powered)
Shift                Horizontal    ±30% (powered)
Keystone correction range*5 Vertical ±30°, horizontal ±25°
Installation                           Ceiling/floor, front/rear
Built-in speaker                    3.7 cm round shape × 1, output power: 10.0 W (monaural)
Terminals        HDMI IN     HDMI 19-pin x 2 (Deep Color, compatible with HDCP),
audio signal: Linear PCM (Sampling frequency: 48 kHz/44.1 kHz/32 kHz)
                        RGB 1 IN    BNC x 5 (RGB or YPBPR/YCBCR x 1), shared with VIDEO IN (S-video/composite video)
                        RGB 2 IN    D-Sub HD 15-pin (female) x 1
                        VIDEO IN   Pin jack x 1 (composite video)
                        MONITOR OUT       D-sub HD 15-pin (female) x 1 (RGB x 1) (compatible with RGB or YPBPR/YCBCR)
                        AUDIO IN  Pin jack x 2 (L/R x 1), M3 x 2 (L-R x 2)
                        AUDIO OUT M3 x 1 (L-R x 1) for output (variable)
                        SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                        REMOTE 1 IN          M3 x 1 for wired remote control
                        REMOTE 2 IN          D-sub 9-pin (female) x 1 for external control (parallel)
                        LAN             RJ-45 x 1 for network connection, 10Base-T, 100Base-TX, compatible with PJLink™
                        DIGITAL LINK        RJ-45 x 1 for network and DIGITAL LINK connection,
100Base-TX, compatible with PJLink™, HDCP, Deep Color
                        USB-A         2 (Network/Wireless x 1, 5 V/0.9 A x 1)
Operation noise*3                35 dB (lamp power: Normal), 29 dB (lamp power: ECO)
Filter                                     x1, replacement cycle: up to 15,000 hours*6
Mechanical shutter               Yes
Cabinet materials                  Molded plastic (PC + ABS)
Dimensions (W x H x D)     PT-EW550L      498 x 145*7 x 398.3 mm (19-19/32 x 5-23/32*7 x 15-11/16 in) (with supplied lens)
Weight*8        PT-EW550L Approx. 9.0 kg (19.8 lbs) (with supplied lens)
Operating environment        Operating temperature: 0-45 °C (32-113 °F)*9,
operating humidity: 20-80 % (no condensation)

Note:                                    The PT-EZ590L/EW650L/EW550L delivers the same performance as the PT-EZ590/EW650/EW550, but comes without a lens.
*1 When Standby Mode is set to Eco, network functions such as power on over LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*2 This is the maximum value when the lamp is turned on for 2 hours and off for 0.25 hours. If the lamp is turned on more times or kept on for a long time, lamp replacement cycle will shorten. Usage environment affects the duration of the lamp.
*3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4 Input signals that exceed supported resolution will be converted.
*5 With the supplied lens. Value differs when the correction for both directions is operated.
*6 Usage environment affects the duration of the filter.
*7 With legs at shortest position.
*8 Average value. May differ depending on models.
*9 Operating temperature range is 0 °C to 40 °C (32 °F to 104 °F) when used at altitudes from 1,400 m to 2,700 m (4,593 ft to 8,858 ft) above sea level. Also, if ambient temperature exceeds 40 °C (104 °F) (35 °C [95 °F] at high altitude), lamp power may automatically switch to Eco to in order to protect the projector.
