General  DLP™ chip  Panel size         16.5 mm (0.65 inches) diagonal, 16:10 aspect ratio
                                    Display method          DLP™ chip x 1, DLP™ projection system
                                    Pixels               1,024,000 (1,280 x 800) pixels
              Lens                                       Manual zoom (2x zoom), manual focus F 2.0-3.4, f 21.5-43.0 mm
              Lamp                                     300 W (max. 310 W) UHM lamp
              Screen size                             1.02-7.62 m (40-300 inches), 16:10 aspect ratio
              Brightness*1                          4,000 lumens (lamp mode: NORMAL)
              Center-to-corner uniformity*1         90%
              Contrast*1                             2,000:1 (full on/full off)
              Resolution                             1,280 x 800 pixels (Input signals that exceed this resolution will be converted to 1,280 x 800 pixels.
              Scanning frequency               HDMI/DVI-D           fH: 27 kHz-100 kHz, fV: 24 Hz-120 Hz, dot clock: 25 MHz-162 MHz
                                    RGB                fH: 15 kHz-100 kHz, fV: 24 Hz-120 Hz, dot clock: 162 MHz or lower
                                    YPBPR (YCBCR)     480i (525i): fH 15.75 kHz; fV 60 Hz
576i (625i): fH 15.63 kHz; fV 50 Hz
480p (525p): fH 31.50 kHz; fV 60 Hz
576p (625p): fH 31.25 kHz; fV 50 Hz
720 (750)/60p: fH 45.00 kHz; fV 60 Hz
720 (750)/50p: fH 37.50 kHz; fV 50 Hz
1035/60i: fH 33.75 kHz; fV 60 Hz
1080 (1125)/60i: fH 33.75 kHz; fV 60 Hz
1080 (1125)/50i: fH 28.13 kHz; fV 50 Hz
1080/25p: fH 28.13 kHz; fV 25 Hz
1080/24p: fH 27.00 kHz; fV 24 Hz
1080/24sF: fH 27.00 kHz; fV 48 Hz
1080/30p: fH 33.75 kHz; fV 30 Hz
1080/60p: fH 67.50 kHz; fV 60 Hz
1080/50p: fH 56.25 kHz; fV 50 Hz
                                    Video/S-Video fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
              Optical axis shift                   Vertical          +70% from center of screen (manual)
                                    Horizontal        ±10% from center of screen (manual)
              Keystone correction range     Vertical          ±40°
              Installation                             Ceiling/floor, front/rear
              Terminals      HDMI IN        HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,
VGA (640 x 480) -WUXGA (1,920 x 1,200)*2; compatible with non-interlaced signals only; dot clock: 25-162 MHz
Audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
                                    DVI-D IN        DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF, 1080/25p, 1080/30p, 1080/60p, 1080/50p,
VGA (640 x 480)-WUXGA (1,920 x 1,200)*2; compatible with non-interlaced signals only; dot clock: 25-162 MHz
                                    RGB 1 IN        BNC x 5 (RGB/ YPBPR x 1)
                                    RGB 2 IN        D-sub HD 15-pin (female) x 1 (RGB/ YPBPR x 1)
                                    VIDEO IN      BNC x 1 (composite video)
                                    S-VIDEO IN   Mini DIN 4-pin x 1 (S-Video)
                                    AUDIO IN 1   RCA x 2 (L, R x 1), 0.5 Vrms
                                    AUDIO IN 2   M3 x 1 (L, R x 1), 0.5 Vrms
                                    AUDIO IN 3   M3 x 1 (L, R x 1), 0.5 Vrms
                                    AUDIO OUT  M3 x 1 (L, R x 1) (monitor out: 0-2.0 Vrms, variable)
                                    SERIAL IN     D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                                    REMOTE IN   D-sub 9-pin (female) x 1 for external control (contact control)
                                    LAN                RJ-45 x 1 (for network connection, 10Base-T/100Base-TX, compliant with PJLink™)
                                    WIRELESS MODULE         Connector for optional wireless module ET-WM200 x 1
              Power cord length                 3.0 m (9 ft 10 in)
              Power supply                         100-240 V AC, 5.0-1.9 A, 50/60 Hz
              Power consumption               415 W (500 VA) (0.3 W at 100-120 V AC, 0.4 W at 220-240 V AC with standby mode set to ECO*3, 15 W with standby mode set to NORMAL)
              Dimensions (W x H x D)       332 x 168*4 x 484.5 mm (13-1/16˝ x 6-5/8˝ *4 x 19-1/16˝ ) (including the lens)
              Weight                                   Approximately 8.5 kg (18.7 lbs.)
              Operating temperature           0°C-45°C (32°F-113°F)
              Operating humidity               20%-80% (no condensation)

NOTE                                                  *1: Measurement, measuring conditions and method of notation all comply with ISO 21118 international standards.
*2: Compliant with VESA CVT-RB.
*3: When the standby mode is set to ECO, network functions such as power on over the LAN will not operate. Also, only certain commands can be received for external control using the serial terminal.
*4: With legs at shortest position.
