Power Supply
AC 100-240 V, 50/60 Hz
Power Consumption
500 W (520 VA, 100 V AC), (375 W with OPERATING MODE set to NORMAL, 350 W with OPERATING MODE set to ECO or SILENT, 40 W with the shutter closed, [Picture Mode: Standard, Dynamic Contrast: ON]), (0.5 W with STANDBY MODE set to ECO2, 10 W with STANDBY MODE set to NORMAL), (22 W with STANDBY MODE in AUDIO SETTING set to ON and QUICK STARTUP function disabled, 50 W with QUICK STARTUP function enabled).
DLP chip
Panel size: 17.0 mm (0.67 in) diagonal (16:10 aspect ratio)
Display method: DLP chip x 1, DLP projection system
Pixels: 2,304,000 (1,920 x 1,200) pixels
Lens
2.0x manual zoom (throw ratio: 1.46-2.94:1), manual focus, F 2.0-3.4, f 21.5-43.0 mm
Light source
Laser diode (Laser class: Class 1), Luminance life: 20,000 hours at half luminance (Normal Mode, Temperature: 35 deg. C [95 deg. F], Altitude: 700 m [2,297 ft], Dust: 0.15 mg/m^3)
Screen size
Diagonal: 1.02-7.62 m (40-300 in), 16:10 aspect ratio
Brightness
5,400 lm (center) / 5,200 lm
Center-to-corner uniformity
90 %
Contrast
20,000:1 (full on/full off, Dynamic Mode and Dynamic Contrast: ON)
Resolution
1920 x 1200 pixels
Scanning frequency
HDMI/DVI-D/ DIGITAL LINK: fH: 27-100 kHz, fV: 24-120 Hz, dot clock: 25-162 MHz, 480i (525i), 576i (625i), 480p (525p), 576p (625p), 720 (750)/60p, 720 (750)/50p, 1080 (1125)/60i, 1080 (1125)/50i, 1080 (1125)/25p, 1080 (1125)/24p, 1080 (1125)/24sF, 1080 (1125)/30p, 1080 (1125)/60p, 1080 (1125)/50p, VGA (640 x 480)-WUXGA (1,920 x 1,200), compatible with non-interlaced signals only.
RGB: fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 20-162 MHz
Scanning frequency (cont..)
YPBPR (YCBCR): fH: 15.73 kHz, fV: 59.94 Hz [480i (525i)]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1035 (1125)/60i]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p
Optical Axis Shift
Vertical: +64 %, -44 % (manual)
Horizontal: +34 %, -27 % (manual)
Keystone correction range
Vertical: +/- 40drg., horizontal: +/-20 deg. (up to a total of +/-60 deg. during simultaneous horizontal and vertical correction)
Installation
Ceiling/floor, front/rear, 360-degree free installation
HDMI In
2x HDMI 19-pin (Deep Color, compatible with HDCP),
audio signal: Linear PCM (sampling frequency: 48 kHz/44.1 kHz/32 kHz)
DVI-D In
DVI-D 24-pin (DVI 1.0 compliant, compatible with HDCP, compatible with single link only)
Computer 1 In
1x D-sub HD 15-pin (female) (1x RGB/YPBPR/YCBCR/YC)
Computer 2 In/ 1 Out
1x D-sub HD 15-pin (female) (1x RGB/YPBPR/YCBCR), (input/output selectable using on-screen menu)
Video In
1x Pin jack (composite video)
Audio In 1
2x Pin jack (1x L, 1x R)
Audio In 2
1x M3 (1x L-R)
Audio In 3
1x M3 (1x L-R)
Audio Out
1x M3 (1x L-R) (variable)
Serial In
D-sub 9-pin (female) 1x for external control (RS-232C compliant)
LAN
RJ-45 x 1 for network connection, 10Base-T/100Base-TX, compatible with Art-Net, compliant with PJLink (Class 1)
Digital Link
RJ-45 x 1 for network/DIGITAL LINK connection (video/audio/network/serial control), 100BASE-TX, compatible with Art-Net, Deep Color, HDCP, compliant with PJLink (Class 1)
USB
Type A x 1 (5 V, 900 mA)
Cabinet materials
Molded plastic
Operation Noise
28 dB (Silent Mode), 33 dB (Normal/Eco Mode)
Operating Temperature
0 to 45 deg. C / 32 to 113 deg. F
Operating Humidity
10- 80 % (no condensation)
Dimensions (W x H x D)
498 x 168 x 492mm / 19.61 x 6.61 x 19.37"
Weight
16.3kg / 35.93lbs (Approx.)
