DLP™ chip Panel size                                                                      24.1 mm (0.95 inches) diagonal
(4:3 aspect ratio)
                  Display method                                                             DLP™ chip x 3, DLP™ projection system
                  Pixels                                                                            1,470,000 (1,400 x 1,050) x 3,
total of 4,410,000 pixels
Refresh Rate                                                                                    120 Hz
Lamp          Normal                                                                          UHM lamp x 4 (432 W), replacement cycle of up to 3,000 hours*3
                  Portrait                                                                          UHM lamp x 4 (432 W), replacement cycle of up to 700 hours
Brightness                                                                                       20,000 lm (four-lamp)
Contrast ratio                                                                                   10,000:1 (full on/full off, in Dynamic iris mode 3)
Resolution                                                                                       1,400 x 1,050 pixels
Lens                                                                                                Optional powered zoom and fixed-focus lenses
Screen size (diagonal)                                                                     1.78-25.4 m (70-1,000 in),
1.78-7.62 m (70-300 in) with the ET-D75LE50,
3.05-15.24 m (120-600 in) with the ET-D75LE90,
1.78-15.24 m (70-600 in) with the ET-D75LE8,
4:3 aspect ratio
Center-to-corner uniformity                                                              90 %
Optical axis shift                                                                              Vertical    ±50 % (±40 % with the ET-D75LE6,
+71 % (fixed) with the ET-D75LE90) (powered)
                  Horizontal                                                                      ±30 % (±20 % with the ET-D75LE6,
±0 % (non-movable) with the ET-D75LE90) (powered)
Scanning frequency                                                                         SDI           SD-SDI             SMPTE ST 259 compliant, [YCBCR 4:2:2 10-bit] 480i, 576i
                         HD-SDI                                                                   SMPTE ST 292 compliant,
[YPBPR 4:2:2 10-bit] 720/50p, 720/60p, 1035/60i, 1080/50i,
1080/60i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p
                         3G-SDI                                                                    SMPTE ST 424 compliant,
[YPBPR 4:2:2 10-bit] 1080/50p, 1080/60p,
[RGB 4:4:4 12-bit /10-bit] 1080/50i, 1080/60i, 1080/25p,
1080/24p, 1080/24sF, 1080/30p
                         Dual-link HD-SDI                                                     SMPTE ST 372 compliant,
[RGB 4:4:4 12-bit /10-bit] 1080/50i, 1080/60i, 1080/25p,
1080/24p, 1080/24sF, 1080/30p,
[X´Y´Z´ 4:4:4 12-bit] 2048 x 1080/24p, 2048 x 1080/24sF
                         Dual-link
3G-SDI        SMPTE ST 425 compliant,
[YPBPR 4:4:4 12-bit / 10-bit] 1080/60p, 1080/50p, 2048 x 1080/60p,
2048 x 1080/50p, 2048 x 1080/48p,
[RGB 4:4:4 12-bit/10-bit] 1080/60p, 1080/50p, 2048 x 1080/60p, 2048 x 1080/50p, 2048 x 1080/48p
                  HDMI/DVI-D/
DIGITAL LINK                                                                                  480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/24p, 1080/24sF,
1080/25p, 1080/30p, 1080/60p, 1080/50p, VGA (640 x 480)-WUXGA*6 (1920 x 1200),
compatible with non-interlaced signals only, dot clock: 25-162 MHz
                  DVI-D/HDMI
simultaneous
input          1920 x 1200p, 1920 x 1080p, 1400 x 1050p, 1366 x 768p, 120 Hz/100 Hz
                  RGB                                                                               fH: 15-100 kHz, fV: 24-120 Hz, dot clock: 13.5-162 MHz
                  YPBPR (YCBCR)                                                            fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1035 (1125)/60i
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 33.75 kHz, fV: 30 Hz [1080 (1125)/30p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p]                                          fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 28.13 kHz, fV: 25 Hz [1080 (1125)/25p]
fH: 27.00 kHz, fV: 48 Hz [1080 (1125)/24sF]
fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
                  Video/YC                                                                       fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Terminals   SDI IN                                                                            BNC x 2 (3G/HD/SD-SDI)
                  DVI-D IN                                                                         DVI-D 24-pin x 1 (DVI 1.0 compliant, compatible with HDCP,
compatible with single link only)
                  HDMI IN                                                                         HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
                  RGB 1 IN                                                                        BNC x 5 (RGB/YPBPR/YCBCR/YC x 1)
                  RGB 2 IN                                                                        D-Sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR x 1)
                  3D SYNC IN/OUT                                                            BNC x 1 (3D timing signal)
                  3D SYNC OUT                                                                BNC x 1 (3D timing signal)
                  SERIAL IN                                                                     D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                  SERIAL OUT                                                                  D-sub 9-pin (male) x 1 for link control
                  REMOTE 1 IN                                                                 M3 x 1 for wired remote control
                  REMOTE 1 OUT                                                             M3 x 1 for link control (for wired remote control)
                  REMOTE 2 IN                                                                 D-sub 9-pin (female) x 1 for external control (parallel)
                  LAN / Digital Link                                                          RJ-45 x 1 (for network, DIGITAL LINK connection, 100Base-TX,
compatible with Art-Net, PJLink™ (class 1), Deep Color, HDCP)
Keystone correction range                                                               Vertical: ±40°*6, horizontal: ±15°
Installation                                                                                       Ceiling/floor, front/rear, portrait
Cabinet materials                                                                             Molded plastic
Power supply                                                                                   200–240 V AC, 50/60 Hz
Power consumption                                                                         2,060 W (0.3 W with STANDBY MODE set to ECO,*1
4 W with STANDBY MODE set to NORMAL.)
Dimensions (W x H x D)                                                                   620 x 255 x 730 mm (24-13/32 x 10-1/32 x 28-3/4 in)
(optional lens, legs and lens cover not included)
Weight                                                                                             Approx. 41 kg (90.4 lbs) (optional lens not included)
Operation noise                                                                               46 dB
Operating temperature                                                                     0–45°C (32–113°F)
Operating humidity                                                                          10– 80 % (no condensation)
