Image sensor 1/3 MOS
Supported Video Codec H.264 / JPEG
Max. Resolution
Max. FPS H.264 60
Super Dynamic / WDR / BLC Enhanced Super Dynamic
Day/Night Day / Night (electrical)
ABF (Auto Back Focus) / Focus Assist Focus Assist
IR LED -
Min. Illumination Color (lx) 0.01
Min. Illumination B/W (lx) 0.008
Lens f=2.8-10mm, F1.6
Angular field of view H: 28-99 deg. V: 16-54 deg.
Pan / Pan Range -240 - +120 deg.
Tilt / Tilt Range -85 - +85 deg.
Optical Zoom 3.6x
with Extra Zoom 7.2x
Audio -
SD memory Card Slot 1
External I/O 3/2
Vandal Resistant IEC62262, IK10
Water and Dust Resistance -
Rain Wash Coating -
Smart Coding Yes
Temperature (degree, Celsius) MAX 50
MIN -10
Power Source PoE, 12V DC
