Image sensor 1/3 MOS
Supported Video Codec H.264 / JPEG
Max. Resolution 1080p / 2,048 x 1,536
Max. FPS H.264 60
Super Dynamic / WDR / BLC Enhanced Super Dynamic
Day/Night Day / Night (ICR)
ABF (Auto Back Focus) / Focus Assist ABF
IR LED Yes
Min. Illumination Color (lx) 0.07
Min. Illumination B/W (lx) 0
Lens f=2.8-10mm, F1.6
Angular field of view H: 31-112 deg. V: 17-60 deg.
Pan / Pan Range -90 - +90 deg.
Tilt / Tilt Range -90 - +90 deg.
Optical Zoom 3.6x
with Extra Zoom 10.8x
Audio 2-Way (No Built-in MIC)
SD memory Card Slot 1
External I/O 3/2
Vandal Resistant -
Water and Dust Resistance IP66, NEMA 4X
Rain Wash Coating -
Smart Coding Yes
Temperature (degree, Celsius) MAX 50
MIN -40
Power Source PoE, 12V DC
