Image sensor 1/1.7 MOS
Supported Video Codec H.264 / JPEG
Max. Resolution 4K (3,840 x 2,160) / 4,000 x 3,000
Max. FPS H.264 30(4K)
Super Dynamic / WDR / BLC Wide Dynamic
Day/Night Day / Night (ICR)
ABF (Auto Back Focus) / Focus Assist ABF
IR LED Yes
Min. Illumination Color (lx) 0.3
Min. Illumination B/W (lx) 0.01
Lens f=4.2-25.2mm, F1.6motorized
Angular field of view H: 17-96 deg. V: 9.3-54 deg.
Pan / Pan Range -180 - +180 deg.
Tilt / Tilt Range 0 - +85 deg.
Optical Zoom 6x
with Extra Zoom 18x
Audio 2-Way (No Built-in MIC)
SD memory Card Slot 1
External I/O 3/2
Vandal Resistant IEC62262, IK10
Water and Dust Resistance IP66, NEMA 4X
Rain Wash Coating Yes
Smart Coding -
Temperature (degree, Celsius) MAX 50
MIN -45
Power Source PoE, 12V DC
