Chip Inch Size 1/4
Colour Type Colour / Monochrome
Resolution TVL 640 x 480
Dome Type PTZ
Sensitivity lux 0.0013
Pan Speed o/ sec 400
Digital (DSP) Yes
Tilt Speed o/ sec 400
Mount Type Wall
Focal length 3.8 ~ 114
Rotation Angleso 360 pan, -5 ~ +185 tilt
Presets 256
Compression M-JPEG, JPEG, MPEG-4
Back Light Compensation Yes
Auto Gain Control Yes
White Balance Yes
Electronic Shutter range 1/60 ~ 1/100
S/ N (Signal/ Noise) Ratio dB 52
Signal Mode PAL, NTSC
Video Output 1 Vpp, 75 Ohms
Zoom Ratio x30
Electrical Specifications Voltage: 24 V AC
Power Consumption: 85 W

Network Properties Interface: 10Base-T / 100Base-TX, RJ-45
Network Protocols: TCP/IP, UDP/IP, HTTP, FTP, SMTP, DHCP, DNS, DDNS
Image Frame Rate: 30 fps

Physical Specifications Dimensions mm: 239 x 396
Weight g: 4,900

Environmental Specifications Operating Temp oC: -40 ~ +50
Operating Humidity %: 0 ~ 90
Protection: IP66

System Requirments Web Browser: Microsoft Internet Explorer 7.0, 6.0 SP2

Model Info Super Dynamic III technology delivers 128x wider dynamic range compared to conventional cameras. High sensitivity with day-night function: 0.5 lux (Colour) at F1.4 (WIDE), 0.04 lux (B/W) at F1.4 (WIDE). IR cut filter switches on and off to ensure optimal picture quality in both colour and B/W.
