Power Source: 9 V DC, 300 mA (using the supplied AC adapter)
•Power Source (supplied AC adapter): 120 V AC, 60 Hz, 200 mA
•Data Output/Input Port: 6-conductor modular jack (RS-485, Full duplex) x2
•Serial Port: 9-pin D-sub connector
•Controller Number: 1 to 8 (rotary switch)
•Ambient Operating Temperature: –10 °C to +50 °C (14 °F to 122 °F)
•Unit Number Selection: 1 to 99
•Monitor Number Selection: 1 to 99
•Camera Number Selection: 1 to 256
•Dimensions (W x H x D): Main Unit-290 x 111 x 221 mm (11-7/16" x 4-3/8" x 8-11/16") / 3D Joystick Unit-134 x 146 x 218 mm (5-1/4" x 5-3/4" x 8-9/16")
•Weight (without the AC adapter): Main Unit-1.3 kg (2.86 lbs.) / 3D Joystick Unit-0.8 kg (1.76 lbs
