Panel Type 0.55" DLP x 1
Lamp 190W x 1
Brightness 3,000 lumens
Lens F2.41-2.53, f21.8-24mm
Contrast (Full on / Full off) 4000:1
Resolution (Native / maximum) XGA
H-Sync/V-Sync Range RGB: fH:15-91.1 kHz, fV:24-85.1 Hz
Video Compatibility PAL, PAL-N, SECAM, NTSC, NTSC4.43, PAL-M, PAL60
Screen Size 30" - 300"
Keystone Correction Range Vertical ±40°
Weight Approx 2.3kg
Dimensions (W x H x D) 286 x 100.6 x 192 mm
Power Consumption 218W
Terminals HDMI (19 pin x 1)
PC in (D-sub HD 15-pin x 1)
MON out (D-sub HD 15-pin x 1)
Video in (Pin jack x 1)
Serial in (Mini DIN 3-pin (female) x 1)
Audio in (M3 x 1)
Audio out (M3 x 1 (L-R x 1)
Replacement Lamp ET-LAL320
Optional Accessories ET-PKV100H (High ceiling mount bracket) ET-PKV100S (Low ceiling mount bracket) ET-PKL300B (Bracket assembly)
Standard Accessories Wireless remote control unit Battery Power cord VGA cable
