Product Series Name |
Pharmaceutical Refrigerators |
|
Model |
MPR−514 |
|
External Dimensions |
900 x 600 x 1790 (mm) / 35.4 x 23.6 x 70.5 (inch) |
|
Internal Dimensions |
800 x 465 x 1300 (mm) / 31.5 x 18.3 x 51.2 (inch) |
|
Effective Capacity |
489 liters (17.3 cu.ft.) |
|
External Cabinet |
Galvanized steel with baked on finish |
|
Internal Cabinet |
Stainless steel |
|
Outer Door |
2 sliding doors, Double layer glass with heat reflection film |
|
Insulation |
Rigid polyurethane foamed-in-place (HCFC free) |
|
Shelves & sliding racks |
5 polyester-coated wire shelves Load: 50 kg per shelf, |
|
Outer door lock |
1 |
|
Cooling method |
Forced cool air circulation |
|
Compressor |
Hermetic type, output: 200 W |
|
Evaporator |
Fin and tube For cooling: output 3 W x 1 |
|
Condenser |
Wire and tube, Tube on sheet |
|
Refrigerant |
HFC |
|
Defrosting |
Forced type, fully automatic |
|
Defrost Heater |
73.8 W x 2 |
|
Net weight |
141 kg (300 lbs) |
