External Dimensions |
770 x 870 x 1990 (mm) / 30.3 x 34.3 x 78.3 (inch) |
|
Internal Dimensions |
630 x 600 x 1380 (mm) / 24.8 x 23.6 x 54.3 (inch) |
|
Effective Capacity |
519 liters (18.3 cu.ft.) |
|
Exterior Cabinet |
Painted steel |
|
Internal Cabinet |
Painted steel |
|
Doors |
Painted steel |
|
Insulation |
Vacuum insulation panel + Rigid polyurethane foamed-in place |
|
Shelves |
3 pcs, stainless steel tray |
|
Access Ports |
17 mm diameter, 3 locations (back, bottom left / right corner) |
|
Net Weight |
Approx. 320 kg (705 lbs.) |
|
Compressor |
2 compressors, hermetic 1100 W |
|
Evaporator |
Tube on sheet type |
|
Condenser |
Finless tube type |
|
Refrigerant |
HFC |
|
Temperature Control Range |
– 50 °C to – 86 °C (in 1 °C increments) |
|
Temperature Display |
Digital Display |
|
Alarms |
High / low temperature, Door ajar, Power failure, Remote alarm contact, Part replacement notification, Fan lock alarm, Refrigeration circuit abnormal alarm,Remote alarm contact (Allowable contact capacity: DC 30 V, 2 A) |
|
Accessories |
1 scraper / Vacuum release port cleaning gear, 1 set of keys |
