LCD panel            Panel size                15 mm (0.59 in) diagonal (16:10 aspect ratio)
                          Display method        Transparent LCD panel (x 3, R/G/B)
                          Pixels                     1,024,000 (1,280 x 800) x 3,
total of 3,072,000 pixels
Lamp                                               280 W x 1,
lamp replacement cycle (lamp power: Normal/Eco): 2,500 hours/4,000 hours
Brightness                                        4,800 lm (lamp power: Normal)
Center-to-corner uniformity                  85 %
Contrast ratio                                     3,500:1 (full on/full off,
lamp power: Normal, Iris: On)
Resolution                                        1,280 x 800 pixels
Lens                                                1.6x manual zoom (throw ratio: 1.18-1.90:1),
manual focus, F 1.60-2.12, f 15.28-24.62 mm
Screen size (diagonal)                          0.76-7.62 m (30-300 in), 16:10 aspect ratio
Optical axis shift                                 Vertical: +48 %
Scanning frequency
                          HDMI                      fH: 25-80 kHz, fV: 50-85 Hz, dot clock: 162 MHz or lower
                          RGB (analog)           fH: 15-100 kHz, fV: 50-100 Hz, dot clock: 140 MHz or lower
(Signals exceeding the dot clock rate of 140 MHz are downsampled.)
                          YPBPR (YCBCR)       fH: 15.75 kHz, fV: 60 Hz [480i(525i)]
fH: 31.50 kHz, fV: 60 Hz [480p(525p)]
fH: 45.00 kHz, fV: 60 Hz [720(750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1125(1035)/60i]
fH: 28.13 kHz, fV: 50 Hz [1080(1125)/50i]      fH: 15.63 kHz, fV: 50 Hz [576i(625i)]
fH: 31.25 kHz, fV: 50 Hz [576p(625p)]
fH: 37.50 kHz, fV: 50 Hz [720(750)/50p]
fH: 33.75 kHz, fV: 60 Hz [1080(1125)/60i]
                          Video/S-Video           fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Terminals
                          HDMI IN                   HDMI 19-pin x 1 (Deep Color, compatible with HDCP)
480p, 576p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p,
VGA (640 x 480)-WUXGA (1,920 x 1,200), *6
audio signal: linear PCM (sampling frequencies: 48 kHz, 44.1 kHz, 32 kHz)
                          COMPUTER IN 1        D-sub HD 15-pin (female) x 1 (RGB/YPBPR/YCBCR x 1)
                          COMPUTER IN 2 /
MONITOR OUT      D-sub HD 15-pin (female) x 1 (RGB x 1), (input/output selectable using on-screen menu)
(When Monitor Out is selected, the COMPUTER IN 1 signal is output.)
                          VIDEO IN                 Pin jack x 1 (Composite VIDEO)
                          S-VIDEO IN              Mini DIN 4-pin x 1 (S-VIDEO)
                          AUDIO IN                 Pin jack x 2 (L/R x 1) for VIDEO/S-VIDEO input
                          COMPUTER
AUDIO IN 1           M3 x 1 (L-R x 1)
                          COMPUTER
AUDIO IN 2
(MIC IN)               M3 x 1 (L-R x 1) for audio input or for microphone connection (variable)
                          AUDIO OUT             M3 x 1 (L-R x 1) for output (variable)
                          SERIAL IN                D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                          LAN                       RJ-45 x 1 (for network connection, 10Base-T/100Base-TX,
compliant with PJLink™ (class 1))
Keystone correction range                    Vertical: ±30° (±20° when Real-Time Keystone)
Installation                                        Ceiling/floor, front/rear
Cabinet materials                                Molded plastic
Power supply                                     100-240 V AC, 50/60 Hz
Power consumption                            365 W (0.3 W when standby mode set to Eco*1,
11.5 W when standby mode set to Network.)
Dimensions (W x H x D)                        379 x 107 x 305 mm (14.9 x 4.2 x 12.0 in)
(with legs at shortest position, not including protruding parts)
Weight                                              approximately 11.5 kg (25.4 lbs)
Operating temperature                         0°C-40°C [32°F-104°F]*7
(less than 1,200 m [3,937 ft] above sea level, Fan control: OFF),
0°C-30°C [32°F-86°F]
(between 1,200 m and 2,000 m [3,937 ft and 6,562 ft] above sea level, Fan control: ON1),
0°C-30°C [32°F-86°F]
(between 2,000 m and 2,700 m [6,562 ft and 8,858 ft] above sea level, Fan control: ON2)
Operating humidity                             20 %-80 % (no condensation)
