General Power supply 100 - 240 V AC, 50/60 Hz
Power consumption 310 W (0.42 W when STANDBY MODE set to ECO,*1
9.5 W when STANDBY MODE set to NETWORK.)
Optical system Optical isolation/Prism synthesis by using a dichroic mirror
LCD panel Panel size 15 mm (0.59 inches) diagonal (16:10 aspect ratio)
Display method Transparent LCD panel (x 3, R/G/B)
Drive system Active matrix
Pixels 1,024,000 pixels (1,280 × 800) x 3, Total: 3,072,000 pixels
Pixel configuration Stripe
Lens Fixed (0.5:1 throw ratio), manual focus F = 1.8, f = 6.68 mm
Lamp 230 W UHM lamp (The lamp replacement cycle is 4,000 hours*2)
Screen size (diagonal) 1.52 - 2.79 m (60 - 110 inches) (16:10 aspect ratio)
Color reproducibility Full color (16,777,216 colors)
Brightness*3 2,500 lm (lamp power: Normal)
Center-to-corner uniformity*3 80%
Contrast*3 500:1 (full on/full off, lamp power: Normal)
Resolution 1,280 × 800 pixels (Input signals that exceed this resolution will be converted to 1,280 × 800 pixels.)
Scanning frequency HDMI (Horizontal) 25-80 kHz; (Vertical) 50-85 Hz; (Dot clock) 162 MHz or lower
RGB (analog) (Horizontal) 15-100 kHz; (Vertical) 50-100 Hz; (Dot clock) 140 MHz or lower (Signals exceeding the dot clock rate of 140 MHz are downsampled.)
YPBPR (YCBCR) fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
Video/S-Video fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Optical axis shift 10:-1.44 (fixed)
Keystone correction range Vertical: ±20°
Installation Ceiling/floor, front/rear (Menu setting)
Built-in speaker 3.7 cm round shape x1, output power 10 W (monaural)
Terminals HDMI IN (HDMI 19-pin) x 1 (compatible with HDCP)
Audio signal Linear PCM (Sampling frequency: 48 kHz/44.1 kHz/32 kHz)
COMPUTER IN 1 D-sub HD 15-pin (female) x 1 [RGB/YPB(CB)/PR(CR)x 1]
COMPUTER IN 2 / MONITOR OUT D-sub HD 15-pin (female) x 1 (RGB x 1) (input/output selectable using on-screen Menu)
(When Monitor Out is selected, the COMPUTER IN 1 signal is output.)
VIDEO IN RCA pin × 1
S-VIDEO IN Mini DIN 4-pin × 1
COMPUTER AUDIO IN M3 x 1 (L-R x 1)
AUDIO IN RCA pin x 2 (L-R x 1) for VIDEO/S-VIDEO input
AUDIO OUT M3 x 1 (L-R x 1)
SERIAL IN D-sub 9-pin (male) × 1 for external control (RS-232C compliant)
LAN (RJ-45)× 1 (for network connection, 100BASE-TX/10BASE-T, compliant with PJLink™ (class 1))
USB -
Power cord length 2.0 m (6&7")
Cabinet materials Molded plastic (PC)
Dimensions (W × H × D) 350 × 143 × 382 mm
(13-25/32" × 5-5/8" × 15-1/32")
(with legs at shortest position)
Weight Approx.4.7 kg (10.4 lbs)*4
Noise level 36 dB (Lamp power: Normal); 29 dB (Lamp power: Eco)
Operating temperature 0°C- 35°C [32°F-95°F] (less than 1,200 m [3,937 ft] above sea level),
0°C- 30°C [32°F-86°F] (between 1,200 m and 2,700 m [3,937 ft to 8,858 ft] above sea level)
Operating humidity Operating humidity: 20% - 80% (no condensation)
NOTE *1 When Standby mode is set to Eco, network functions such as standby on via LAN are not available. Only certain commands can be received for external control using the serial terminal.
*2 This is the maximum value when the lamp power is set to Eco mode where the lamp is turned on for 2 hours and off for 0.25 hours. If the lamp is turned on more times or kept on for a long time, the lamp replacement cycle will shorten. In Normal mode, the lamp replacement cycle is 3,000 hours. The usage environment affects the duration of the lamp.
*3 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*4 The above values are averages. Actual values may be different according to the product.
