Power supply                                           100–240 V AC, 50/60 Hz
Power consumption                                  301 W (0.5 W when STANDBY MODE set to ECO,*1
6.0 W when STANDBY MODE set to NORMAL.*2)
DLP™ chip                 Panel size                 14 mm (0.55 in) (4:3 aspect ratio)
                               Display method         DLP™ chip x 1 DLP™ system
                               Pixels                      786,432 (1,024 x 768) pixels
Lens                                                       Fixed (0.626:1 throw ratio), manual focus F = 2.8, f = 7.26 mm
Lamp                                                      240 W UHM lamp
Lamp replacement cycle
(Normal / Eco / AUTO)                                3,000 / 4,000 (Eco1, Eco2) / 7,500 hours
Screen size (diagonal)                                1.02-5.08 m (40-200 in), 4:3 aspect ratio
Brightness                                               3,000 lm
Center-to-corner uniformity ratio *2               80%
Contrast                                                  7,500:1
(full on/full off, During RGB signal input, Color mode: Dynamic, Lamp power: AUTO)
Resolution                                               1,024 x 768 pixels
(Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.)
Scanning frequency     HDMI                       fH: 15-91.1 kHz, fV: 24-85.1 Hz, dot clock: 25-162 MHz
                               RGB (analog)            (fH: 15-91.1 kHz, fV: 24-85.1 Hz, dot clock: 162 MHz or lower
                               YPBPR (YCBCR)        fH: 15.75 kHz, fV: 60 Hz [480i (525i)]
fH: 31.50 kHz, fV: 60 Hz [480p (525p)]
fH: 45.00 kHz, fV: 60 Hz [720 (750)/60p]
fH: 33.75 kHz, fV: 60 Hz [1080 (1125)/60i]
fH: 27.00 kHz, fV: 24 Hz [1080 (1125)/24p]
fH: 56.25 kHz, fV: 50 Hz [1080 (1125)/50p            fH: 15.63 kHz, fV: 50 Hz [576i (625i)]
fH: 31.25 kHz, fV: 50 Hz [576p (625p)]
fH: 37.50 kHz, fV: 50 Hz [720 (750)/50p]
fH: 28.13 kHz, fV: 50 Hz [1080 (1125)/50i]
fH: 67.50 kHz, fV: 60 Hz [1080 (1125)/60p]
                               Video                      fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60],
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM]
Installation                                              Ceiling/floor, front/rear (Menu setting)
Built-in speaker                                        7 x 4 cm oval shape x 1, output power 8 W (monaural)
Optical axis shift                                       10:-1.5
Keystone correction range                          Vertical: ±40° (manual)
Terminals                  HDMI IN                   HDMI 19-pin x 1 (Deep color, compatible with HDCP),
audio signal: linear PCM (Sampling frequency: 48 kHz, 44.1 kHz, 32 kHz)
                               COMPUTER IN 1        D-sub HD 15-pin (female) x 1 [RGB/YPB(CB)/PR(CR) x 1]
                               COMPUTER IN 2        D-sub HD 15-pin (female) x 1 [RGB/YPB(CB)/PR(CR) x 1]
                               MONITOR OUT          D-sub HD 15-pin (female) x 1 (The signal selected from computer inpupt 1/2 is output.)
                               VIDEO IN                  Pin jack x 1
                               SERIAL IN                D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
                               AUDIO 1 IN               M3 x 1 (L-R x 1) (for COMPUTER)
                               AUDIO 2 IN               M3 x 1 (L-R x 1) (for VIDEO)
                               AUDIO OUT              M3 x 1 (L-R x 1) for output (variable)
                               LAN                        RJ-45 x 1 (for network connection, 100BASE-TX/10BASE-T,
compliant with PJLink™ (class 1))
                               Mini USB                  1 (for interactive function)
Power cord length                                     3.0 m (9'10")
Cabinet material                                        Molded plastic (PC)
Dimensions (W x H x D)                              288 x 106 x 270.5 mm (11-11/32 x 4-3/16 x 10-21/32 in)
Weight                                                    Approximately 2.7 kg (6 lbs)
Noise level                                               37 dB (Lamp power: Normal),
32 dB (Lamp power: Eco1),
29 dB (Lamp power: Eco2)
Operating Temperature                              5-40°C [41-104°F] (Less than 750 m [2,500 ft] above sea level),
5-35°C [41-95°F] (between 750 and 1,500 m [2,500 ft and 5,000 ft] above sea level),
5-30°C [41-86°F] (between 1,500 and 3,000 m [5,000 ft and 10,000 ft] above sea level)
Operating humidity                                   20%-80% (no condensation)
